In the world of plastic manufacturing, the quality of your final product is often determined by a single, critical parameter that is set at the very beginning of the line. If you are in the business of producing blown film, you know that achieving the perfect balance between strength, clarity, and thickness can sometimes feel more like art than science.

However, there is a specific, measurable value that demystifies this process: the Blow-Up Ratio (BUR) . Understanding this concept is essential for any engineer or manufacturer looking to optimize production and reduce material waste.

This article will explain what the Blow-Up Ratio is, how to calculate it, and why it is the most influential factor in determining the quality of your film.

Defining the Blow-Up Ratio

The Blow-Up Ratio (BUR) is a fundamental parameter in the blown film extrusion process. It describes the amount of radial expansion the molten plastic undergoes after it exits the die .

In simple terms, BUR is a comparison between the size of the die and the size of the final inflated bubble. When the plastic tube (or “parison”) is extruded, it is immediately inflated by internal air pressure. This expansion stretches the polymer molecules in the transverse direction (TD), which is across the width of the film. The degree of this stretching is precisely what the BUR quantifies .

How to Calculate Blow-Up Ratio

Calculating the Blow-Up Ratio is relatively straightforward. The basic formula compares the final diameter of the bubble to the diameter of the die:

BUR = Final Bubble Diameter / Die Diameter

However, on the production floor, it is much more common to measure the “lay-flat” width—the flattened tube of film that is wound onto the roll. To find the BUR using the lay-flat width, you can use the following conversion, which accounts for the fact that the lay-flat width represents half the circumference of the bubble :

BUR = (Lay-flat Width × 2/π) / Die Diameter

*For example: If you have a die diameter of 100 mm and you produce a lay-flat width of 471 mm, the calculation would be: Bubble Diameter = 471 mm × 0.637 = 300 mm. Therefore, BUR = 300 mm / 100 mm = 3:1.*

This 3:1 ratio is a common benchmark in the industry, indicating the bubble expanded to three times its original diameter .

Why BUR is Critical for Film Quality

The Blow-Up Ratio is not just a number to track; it is a control lever that directly dictates the physical properties of your film. By manipulating the BUR, you control the orientation of the polymer chains. This orientation determines whether the film is strong lengthwise (Machine Direction) or widthwise (Transverse Direction) .

Impact on Mechanical Strength

  • Low BUR (e.g., 1.5:1 to 2.5:1): With low radial expansion, the polymer chains remain largely oriented in the machine direction (the direction they are pulled). This results in film that is very stiff and strong lengthwise but weak and prone to splitting across the width . This is often suitable for heavy-duty bags where the primary stress is along the length.
  • High BUR (e.g., 3:1 to 5:1): A higher ratio forces the molecules to stretch and orient in the transverse direction. This creates a “balanced” film where the strength is more equal in both directions. This balance is crucial for shrink films or packaging where the material must withstand stress from all angles .

Impact on Optical Properties

If your application requires high clarity (such as food packaging), BUR plays a vital role. At higher BURs, the rapid stretching of the bubble limits the growth of large, light-scattering crystals within the film. This results in a smoother surface, lower haze (cloudiness), and higher gloss . A film produced with a BUR of 4:1 will generally be significantly clearer than one produced at 2:1.

Impact on Thickness Uniformity

While BUR helps make film thinner (since the same amount of material is spread over a larger area), it also introduces challenges. Very high BURs (above 5:1) can lead to bubble instability. If the bubble wobbles or fluctuates due to air currents or temperature variations, it results in uneven thickness across the film’s width, creating weak spots .

Optimizing BUR for Different Polymers

It is important to note that there is no “one-size-fits-all” BUR. Different polymers behave uniquely under stress due to their molecular structure .

  • Low-Density Polyethylene (LDPE): Highly flexible and forgiving. It typically runs well at BURs between 2:1 and 4:1 .
  • High-Density Polyethylene (HDPE): Stiffer than LDPE. It often requires a higher BUR (between 3:1 and 6:1) to achieve a good balance of stiffness and tear resistance, preventing it from splitting easily .
  • Polypropylene (PP) and Polyesters (PET): These materials have narrower processing windows and require precise control of BUR to avoid instabilities like helical wavy lines .

By carefully selecting and controlling the BUR, manufacturers can tailor the “balance” of the film. For instance, if you are experiencing issues with bags splitting at the seal, it often indicates that the BUR is too low, causing weak transverse direction strength .

Conclusion

The Blow-Up Ratio is far more than a simple geometric measurement; it is the defining factor that translates raw polymer pellets into a high-performance film. By understanding how BUR affects molecular orientation, you can move from simply “making film” to engineering specific properties like tensile strength, tear resistance, and optical clarity.

Mastering your BUR settings allows you to troubleshoot issues, reduce material waste by optimizing thickness, and produce a consistent product that meets exact specifications. Whether you need stiff, unidirectional film or balanced, crystal-clear wrap, controlling the blow-up ratio is the key to unlocking the full potential of your extrusion line.
